What is Tripod Turnstile gate?

A Tripod turnstile gate is the most basic type of pedestrian turnstile gate, composed of the chassis, mechanism, and three blocking rods that stop or release by rotating 120° each time. Its components include chassis, mechanism, drive control board, motor, limit, direction indicator board, access control part, optional counter, etc. The metal rod (rod length standard 50cm) forms a spatial triangle as the blocking body (brake rod). It is made of 304 or 316 stainless steel, which is durable and not easy to deform. The blocking and releasing are achieved by rotation.

The tripod barrier gate may be used in conjunction with a smart card fingerprint, bar code as well as other identification system equipment to create an intelligent access control system. It can be combined with computer attendance control, access control and charge administration, ticket systems as well as other software to create an efficient access control management system which is able to perform the tasks of attendance control, access control consumption tickets, sales of tickets as well as current restrictions and more.

Tripod turnstile mechanism:

The mechanical mechanism means that the blocking rod needs to be released manually after the control is released; after release, the other rod stays in the horizontal position after passing through the hydraulic damping device of the mechanism. It can be released after the control is released again. The pushrod only needs 0.5kg thrust.

The electric mechanism is equipped with a motor in the tripod turnstile barrier. After the tripod turnstile gate is released from control, the blocking rod will move forward by an angle. When the pedestrian contacts the trigeminal blocking rod again, the motor will rotate the blocking rod until the other rod returns to the horizontal position and completes the release action.

Tripod Turnstile gate

Types of tripod turnstile gate

The turnstiles for tripods can be classified into mechanical type’s semi-automatic, and full-automatic type, based on the control mode of mechanism.  According to the design it's divided into a vertical tripod turnstile or a bridge turnstile. The gate for the vertical tripod is small in size and is fairly easy to put in. A bridge-truncated turnstile gate comes with an extended channel and better security.

  • Full automatic tripod turnstile gate:
  • Semi-automatic tripod turnstile gate:
  • Manual tripod turnstile gate:


Application site of tripod turnstile:

The tripod barrier turnstile gate is modern control equipment for the smooth flow of people. It is used where the entry and exit of personnel need to be controlled, provides an orderly and civilized way of passage for the person entering and leaving, and eliminates illegal entry and exit. Such as intelligent community, convention and exhibition, meeting hall, canteen, hotel, museum, gymnasium, club, subway, station, wharf, tourist attractions, convention and Exhibition Center, swimming pool, and other places.

The development of science and technology has improved people’s quality of life and made people’s lives more convenient. More and more people use the turnstile gate in their life.



  • Railway tripod turnstile gate: it is widely used in some transportation hubs with a large flow of people, such as subway, light rail, high-speed rail, and so on. These places are often in and out of chaos and difficult to manage. The intelligent tripod barrier turnstile gate can well solve the traffic problem.
  • Supermarket tripod turnstile gate: it is generally used for the import and export of supermarkets. It mainly plays a role in preventing congestion and traffic diversion, ensuring smooth passage of pedestrians. At the same time, the passage is spacious and people who can pass can also pass.
  • Community tripod turnstile gate: in order to ensure the safe management of residential areas, locks have been installed in many residential areas, residents’ lives have become more stable, theft cases have been reduced, and some violators and salesmen have been prevented from entering residential areas to a certain extent.
  • Office building tripod turnstile gate: now many companies have also installed intelligent tripod barrier turnstile gates to facilitate employees’ attendance, which is used to count and monitor the commuting time.
  • College library tripod turnstile gate: it is mainly used in the import and export of university libraries. It enters the library for learning and reading by swiping a card or face. At the same time, it also establishes the management image of the library, standardizes the internal management system, and improves the level.

 Tripod Turnstile

Advantages of tripod turnstile:

As the most commonly used intelligent turnstile gate, the tripod turnstile gate is often seen in the talent market, scenic spots, construction sites, and large supermarkets. The reason why the tripod type turnstile gate can be favored by customers and widely used is mainly due to its advantages:

  • The tripod barrier turnstile is convenient and fast to use
  • Versatility of tripod turnstile gate
  • Safety of tripod turnstile gate
  • Advanced technology and wireless network management system.
  • The tripod turnstile gate expansion is convenient and practical
  • Off-line operation of tripod turnstile gate
  • Data transmission security
  • The tripod turnstile gate is easy to maintain, economical and practical:
  • Management flexibility
  • The tripod turnstile gate is simple and easy to use
  • It has strong dust and water resistance and strong adaptability to the environment



Why use tripod turnstile:

The pedestrian turnstile gate is the product of the development of a new era. It is a popular access control management product in recent years. Among them, the tripod turnstile gate is a common pedestrian turnstile gate product, which is widely used in the import and export of stations, docks, tourist attractions, exhibitions, natatoriums, and other channels.

  • Diversified identification methods
  • Good water resistance
  • Anti-tailing Technology
  • Easy to use
  • High safety
  • Economy Control



Difference between tripod turnstile & flap barrier:

With the development of science and technology, pedestrian turnstile gates are more and more widely used in life. Among them, flap barrier gate and tripod turnstile are widely used at present. What are the differences between tripod barrier turnstile gate and flap barrier turnstile?

Difference between tripod turnstile gate and flap barrier:

  • In terms of channel function, the channel of the flap barrier gate is very convenient for the towing of luggage, while the tripod turnstile gate is inconvenient for the towing of luggage.
  • In terms of working mode, the flap barrier gate is driven by a motor, while most tripod turnstile gates work by the combination of metal limit + mechanical reset + manual propulsion.
  • In terms of opening time, due to the different working mechanisms of the tripod turnstile gate and flap barrier gate, the opening speed is also different. The opening and closing time of the flap barrier is about 0.2 seconds, and the opening and closing time of the tripod turnstile gate is about 1 second.
  • In terms of passage time, because the shapes of the tripod turnstile gate and the flap barrier gate are different, the passage time of the tripod turnstile gate and the flap barrier is different. The fastest passage speed of the flap barrier gate can reach about 55 people per minute, while the maximum passage speed of the tripod turnstile gate is about 25 people per minute according to the actual calculation.
  • In terms of cost, the tripod turnstile gate is an entry-level channel product, which can only be used for civil level channels, while the flap barrier gate is an intermediate product, which can support high flow place relations such as civil level and rail transit.
  • In terms of performance, the tripod turnstile gate is primary dissuasion equipment, which only plays a guiding role and does not have safety. The flap barrier gate has the functions of an anti-climbing alarm, anti-trailing alarm, anti-pinch electronic eye, and so on. It is a product with a relatively high safety level.


Best Brand of tripod turnstile gate?

  • Varito Tripod turnstile gate
  • Uniqscan Tripod turnstile gate
  • Turbo Tripod turnstile gate
  • Secuera Tripod turnstile gate
  • Shining Tripod turnstile gate

Turnstile Barrier Gate

How much Tripod turnstile gate price in Bangladesh?

Tripod turnstile gate price ranged start from 125,000.00 to 500,000.00 depends on number of Lane.



Best price of Tripod turnstile gate in Bangladesh 2022

Size

Brand

Price (BDT)

Single Lane Tripod turnstile gate

Varito

125,000.00 to 150,000.00

Double Lane Tripod turnstile gate

Varito

250,000.00 to 300,000.00

Triple Lane Tripod turnstile gate

Varito

375,000.00 to 450,000.00

Four Lane Tripod turnstile gate

Varito

5,00,000.00 to 10,00,000.00




Summary

Are you looking for a reliable tripod barrier gate provider company? Germany Computer and Telecom Limited offer you best tripod barrier gate services for all purposes. We are dedicatedly Importer, Supplier and Wholesaler of best quality Tripod Turnstile that features solenoid locking system and 360 degree movement with built in bi-directional operation. Our turnstiles have superior locking which prevents them from rotating back to original position after it has moved 25 degree from its rest position. They are supported by hydraulic damping which makes the head to come back smoothly to the rest position. Positive action lock prevents entry of more than one person at a time. We are the best Turnstile Gate supplier who ensures Original and Quality Product at every side. Our product ensures international standard like CE, ISO and others certifications from related authority. GCTL supply various types of turnstile gate systems Such as Waist-high Turnstile gate system, Drop arm Optical Turnstile gate, Mechanical turnstile barrier gate, Entrance/Exit Turnstile gate, Parking barrier gate, Industrial grade Turnstile gate, Vehicle Access Control, Auto gate system in every type of needs
