System
|
|
Main Processor
|
Quad-core embedded processor
|
|
Operating System
|
Embedded LINUX
|
|
Display
|
|
Interface
|
1 HDMI, 1 VGA
|
|
Resolution
|
3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768
|
|
Multi-screen Display
|
1/4/8/9/16
|
|
OSD
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording
|
|
Video Detection and Alarm
|
|
Trigger Events
|
Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips
|
|
Video Detection
|
Motion Detection, MD Zones: 396(22×18), Video Loss & Tampering
|
|
Alarm input
|
4 Channel, Low Level Effective,
Green Terminal Interface
|
|
Relay Output
|
2 Channel, NO/NC Programmable,
Green Terminal Interface
|
|
Playback and Backup
|
|
Playback
|
1/4/8/16
|
|
Search Mode
|
Time/Date, Alarm, MD & Exact search
(accurate to second), Smart search
|
|
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow Play,
Next File, Previous File, Next Camera,
Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
|
|
Backup Mode
|
USB Device/Network
|
|
Storage
|
|
Internal HDD
|
2 SATA III Port, Up to 6 TB capacity for each HDD
|
|
HDD Mode
|
Single
|
|
eSATA
|
N/A
|
|
Auxiliary Interface
|
|
USB
|
2 USB Ports (1 USB2.0, 1 USB3.0)
|
|
RS232
|
N/A
|
|
RS485
|
N/A
|
|
Third-party Support
|
|
Third-party Support
|
Dahua, Arecont Vision, AXIS, Bosch, Brickcom,
Canon, CP Plus, Dynacolor, Honeywell, Panasonic,
Pelco, Samsung, Sanyo, Sony, Videotec, and more
|
|
Audio and Video
|
|
IP Camera Input
|
16/32 Channel
|
|
Two-way Talk
|
1 Channel Input, 1 Channel Output, RCA
|
|
Recording
|
|
Compression
|
H.265/H.264
|
|
Resolution
|
8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc.
|
|
Record Rate
|
200Mbps
|
|
Bit Rate
|
16Kbps ~ 20Mbps Per Channel
|
|
Record Mode
|
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop
|
|
Record Interval
|
1 ~ 120 min (default: 60 min), Pre-record:
1 ~ 30 sec, Post-record: 10 ~ 300 sec
|
|
Network
|
|
Interface
|
1 RJ-45 Port (10/100/1000Mbps)
|
|
Ethernet Port
|
1 Independent 1000Mbps Ethernet Port
|
|
PoE
|
16 ports (IEEE802.3at/af)
|
|
Network Function
|
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP,
IP Search (Support Dahua IP camera, DVR, NVS, etc.), Easy4ip
|
|
Max. User Access
|
128 users
|
|
Smart Phone
|
iPhone, iPad, Android
|
|
Interoperability
|
ONVIF 2.4, CGI Conformant
|
|
Electrical
|
|
Power Supply
|
AC100V ~ 240V, 50 ~ 60 Hz
|
|
Power Consumption
|
NVR: <13.2W (Without HDD)
|
|
PoE: Max 25.5w for single port, 130w in total
|
|
Environmental
|
|
Operating Conditions
|
-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
|
|
Storage Conditions
|
-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
|
|
Construction
|
|
Dimensions
|
1U, 375mm×327.5mm×53mm
(14.8" x 12.9" x2.1")
|
|
Net Weight
|
2.7kg (6.0 lb) (without HDD)
|
|
Gross Weight
|
4.4kg(9.7lb)(without HDD)
|
|
Certifications
|
|
CE
|
EN55032, EN55024, EN50130-4, EN60950-1
|
|
FCC
|
Part 15 Subpart B, ANSI C63.4-2014
|
|
UL
|
UL60950-1+CAN/CSA C22.2 No.60950-1
|
